2000 W Wind Energy Solar Charge Controller 12 V / 24 V / 48 V Automatic Identification with LCD Display – Wind: 1000 W + Solar: 1000 W Wind Turbine with Dump Load (Colour: 900 W, Size) : 12 V

Price: €184.42 - €177.08
(as of Mar 12,2023 21:46:50 UTC – Details)

12V / 24V Automatic Identification:
800W wind solar hybrid system controller: 300W wind energy + 500W light energy

900W Wind Solar Hybrid System Controller: 400W Wind Power + 500W Light Energy

1100W wind solar hybrid system controller: 500W wind energy + 600W light energy

1400W wind solar hybrid system controller: 600W wind energy + 800W light energy

24V / 48V Automatic Identification:
1800W wind solar hybrid system controller: 800W wind energy + 100W light energy

2000W wind solar hybrid system controller: 1000W wind energy + 1000W light energy

2200W wind solar hybrid system controller: 1200W wind energy + 1000W light energy

2700W wind solar hybrid system controller: 1500W wind energy + 1200W light energy

1. Any battery type can be used. 2. Parameters can be customized. 3. Voltage and current display. 4 load working modes
5. Super power use is not bad machine. 6. The failure rate is very low
ligent design succinct structure, control powerful, stable performance, safety and reliability of the products.
Boost charging function to solve the low charging efficiency due to the low wind speed(need to customize).
LCD display battery voltage and power. Professional digital ligent control.
Colour: black.
Material: ABS + electronic components.
System rated voltage: 12 V / 24 V / 48 V (automatic identification).
Photovoltaic (PV) modules power: 1200 W (max.)
Wind power generator power: 1500 W (max.)
Charging current: 37.5 A.
Filling protection: 28.8 V +/-1%.
Float filling: 27.6 V +/-1%.
Filling recovery: 26.4 V +/-1%.
Temperature compensation: -48 mV/℃.
Over discharge disconnect (dc): 21.8 V +/-1%.
Over discharge recovery (dc): 24.6 V +/-1%.
Over-voltage cut off (dc): 32.0 V +/-1%.
Over-voltage recovery (dc): 30.0 V +/-1%.
Unload current (dc): ≤0.1A.
Voltage drop (dc): ≤0.5 V.
Control mode: PWM.
Display parameters: voltage
OS: The charging part of the wind turbine has booster MPT technology that allows it to charge continuously and efficiently, even at low wind speeds. Continuous discharge function including external dump charge resistor solar panel charging uses PWM technology through MOS tube in series.
Intelligent and stable system: the parameters are perfectly adjusted according to the choice of the battery type. Users can also adjust according to their own needs. This system has been intelligently updated to control the charging voltage completely stable.
Adjustable parameters: Renewable energy regulators provide a current limiting charging mode. If the power of the solar panel is too large and the charging current is higher than the rated value, the controller automatically reduces the charging power so that the solar panel works below the rated value charging current.
Protection function: multiple protection: reverse polarity protection, battery interruption protection, battery reverse polarity protection, overwind speed and over voltage, lightning protection, overload protection, etc.
